STR12 series electric slip ring
  • Through hole slip is specially designed through bore for hydraulic or pneumatic rotaing shaft installation
  • Current from 2A to 10A, larger current can be customized
  • Metal housing for better protection. Integrated structure, easy installation

Features

  • 2-48 circuits model
  • Speeds up to 600 RPM
  • Gold-on-gold contacts
  • Precision ball bearings for long life
  • Flying leads

Benefits

  • Extremely compact
  • Custom mechanical integration features
  • Low torque
  • 360° continuous rotation
  • Rapid delivery
MODEL TOTAL CIRCUITS Power(10A) Signal(2A) VOLTAGE (AC/DC V) LENGTH LEAD WIRE LENGTH
STR12-P2 2 2 --- 240 1.06"(27mm) 11.8"(300mm)
STR12-S2 2 --- 2 240 1.06"(27mm) 11.8"(300mm)
STR12-P3 3 3 --- 240 1.18"(30mm) 11.8"(300mm)
STR12-P2S2 4 2 2 240 1.29"(33mm) 11.8"(300mm)
STR12-P4 4 4 --- 240 1.29"(33mm) 11.8"(300mm)
STR12-S6 6 --- 6 240 1.54"(39.2mm) 11.8"(300mm)
STR12-P6 6 6 --- 240 1.54"(39.2mm) 11.8"(300mm)
STR12-P12 12 12 --- 240 2.25"(57.2mm) 11.8"(300mm)
STR12-S12 12 --- 12 240 2.25"(57.2mm) 11.8"(300mm)
STR12-P6S12 18 6 12 240 2.91"(74mm) 11.8"(300mm)
STR12-S18 18 --- 18 240 2.91"(74mm) 11.8"(300mm)
STR12-P18 18 18 --- 240 2.91"(74mm) 11.8"(300mm)
STR12-P12S12 24 12 12 240 3.59"(91.2mm) 11.8"(300mm)
STR12-S24 24 --- 24 240 3.59"(91.2mm) 11.8"(300mm)
STR12-P24 24 24 --- 240 3.59"(91.2mm) 11.8"(300mm)
STR12-S30 30 --- 30 240 4.26"(108.2mm) 11.8"(300mm)
STR12-S36 36 --- 36 240 4.93"(125.4mm) 11.8"(300mm)
STR12-S48 48 --- 48 240 6.14"(156mm) 11.8"(300mm)
