STR25 series electric slip ring
  • STR25 series are standard through hole slip rings ,through hole 25.4mm
  • Transmit combined high speed data(Ethernet ,USB,Profibus)
  • Typical application:automation equipment,working turntable,camera platform,robotics
  • Standard 2A-10A, Larger current can be customized

Features

  • 2-48 circuits model
  • Speeds up to 600 RPM
  • Gold-on-gold contacts
  • Precision ball bearings for long life
  • Flying leads

Benefits

  • Direction of lead wire exits
  • Custom mechanical integration features
  • Combined with thermocouple and signal
  • 360° continuous rotation
  • IP65,IP68 Optional
MODEL TOTAL CIRCUITS Power(10A) Signal(2A) VOLTAGE (AC/DC V) LENGTH LEAD WIRE LENGTH
STR25-S2 2 --- 2 240 1.26"(32mm) 11.8"(300mm)
STR25-P2 2 2 --- 440 1.26"(32mm) 11.8"(300mm)
STR25-P3 3 3 --- 440 1.38"(35mm) 11.8"(300mm)
STR25-P2S2 4 2 2 240 / 440 1.50"(38mm) 11.8"(300mm)
STR25-P4 4 4 --- 440 1.50"(38mm) 11.8"(300mm)
STR25-S6 6 --- 6 240 1.77"(45mm) 11.8"(300mm)
STR25-P6 6 6 --- 440 1.77"(45mm) 11.8"(300mm)
STR25-S12 12 --- 12 240 2.60"(66mm) 11.8"(300mm)
STR25-P12 12 12 --- 440 2.60"(66mm) 11.8"(300mm)
STR25-P2S10 12 6 6 240 / 440 2.60"(66mm) 11.8"(300mm)
STR25-P4S8 12 6 6 240 / 440 2.60"(66mm) 11.8"(300mm)
STR25-P6S6 12 6 6 240 / 440 2.60"(66mm) 11.8"(300mm)
STR25-P6S12 18 6 12 240 / 440 3.38"(85.8mm) 11.8"(300mm)
STR25-S18 18 --- 18 240 3.38"(85.8mm) 11.8"(300mm)
STR25-P18 18 18 --- 440 3.38"(85.8mm) 11.8"(300mm)
STR25-P10S08 24 10 8 240 / 440 3.38"(85.8mm) 11.8"(300mm)
STR25-P06S18 24 6 18 240 / 440 4.21"(107mm) 11.8"(300mm)
STR25-P12S12 24 12 12 440 4.21"(107mm) 11.8"(300mm)
STR25-S24 24 --- 24 240 4.21"(107mm) 11.8"(300mm)
STR25-P24 24 24 --- 440 4.21"(107mm)) 11.8"(300mm)
STR25-P6S24 30 6 24 240 / 440 4.95"(125.8mm) 11.8"(300mm)
STR25-P18S12 30 18 12 240 / 440 4.95"(125.8mm) 11.8"(300mm)
STR25-P30 30 30 --- 440 4.95"(125.8mm) 11.8"(300mm)
STR25-S30 30 --- 30 240 4.95"(125.8mm) 11.8"(300mm)
STR25-S36 36 --- 36 240 5.83"(148mm) 11.8"(300mm)
STR25-P12S24 36 12 24 240 / 440 5.83"(148mm) 11.8"(300mm)
STR25-P36 36 36 --- 240 5.83"(148mm) 11.8"(300mm)
STR25-S42 42 --- 42 240 6.61"(168mm) 11.8"(300mm)
STR25-P6S36 42 6 36 240 / 440 6.61"(168mm) 11.8"(300mm)
STR25-S48 48 48 --- 240 7.44"(189mm) 11.8"(300mm)
STR25-P12S36 48 12 36 240 / 440 7.44"(189mm) 11.8"(300mm)
STR25-S56 56 -- 56 240 8.50"(216mm) 11.8"(300mm)
STR25-P6S50 56 6 50 240 / 440 8.50"(216mm) 11.8"(300mm)
STR25-P12S44 56 12 44 240 / 440 8.50"(216mm) 11.8"(300mm)
STR25-S72 72 --- 72 240 10.63"(270mm) 11.8"(300mm)
