Through Bore Slip Ring STR50 series
STR50 series electric slip ring

Features

  • 2-100 circuits model
  • Speeds up to 300 RPM
  • Precious metal contacts
  • Precision ball bearings for long life

Benefits

  • Custom mechanical integration features
  • Combined with power, signal, high speed data
  • 360° continuous rotation
  • IP65,IP68 Optional



MODEL TOTAL CIRCUITS Power(10A) Signal(5A) VOLTAGE (AV/DC V) LENGTH(mm) LEAD WIRE LENGTH
STR50-S2 2 --- 2 240 37 11.8"(300mm)
STR50-P2 2 2 --- 600 37 11.8"(300mm)
STR50-P3 3 3 --- 600 40.8 11.8"(300mm)
STR50-S3 3 --- 3 240 40.8 11.8"(300mm)
STR50-P2S2 4 2 2 240 / 600 44.6 11.8"(300mm)
STR50-S6 6 --- 6 240 52.2 11.8"(300mm)
STR50-P6 6 6 --- 600 52.2 11.8"(300mm)
STR50-P2S4 6 2 4 240 / 600 52.2 11.8"(300mm)
STR50-P8S4 12 8 4 240 / 600 75 11.8"(300mm)
STR50-S12 12 --- 12 240 75 11.8"(300mm)
STR50-P12 12 12 --- 600 75 11.8"(300mm)
STR50-P2S10 12 2 10 240 / 600 75 11.8"(300mm)
STR50-P4S8 12 4 8 240 / 600 75 11.8"(300mm)
STR50-P6S6 12 6 6 240 / 600 75 11.8"(300mm)
STR50-P6S12 18 6 12 240 / 600 97.8 11.8"(300mm)
STR50-S18 18 --- 18 240 97.8 11.8"(300mm)
STR50-P18 18 18 --- 600 97.8 11.8"(300mm)
STR50-P10S08 24 10 8 240 / 600 97.8 11.8"(300mm)
STR50-P06S18 24 6 18 240 / 600 120.6 11.8"(300mm)
STR50-P12S12 24 12 12 600 120.6 11.8"(300mm)
STR50-S24 24 --- 24 240 120.6 11.8"(300mm)
STR50-P24 24 24 --- 600 120.6 11.8"(300mm)
STR50-P6S24 30 6 24 240 / 600 143.4 11.8"(300mm)
STR50-P18S12 30 18 12 240 / 600 143.4 11.8"(300mm)
STR50-P30 30 30 --- 600 143.4 11.8"(300mm)
STR50-S30 30 --- 30 240 143.4 11.8"(300mm)
STR50-S36 36 --- 36 240 166.2 11.8"(300mm)
STR50-P12S24 36 12 24 240 / 600 166.2 11.8"(300mm)
STR50-P36 36 36 --- 600 166.2 11.8"(300mm)
STR50-S42 42 --- 42 240 193 11.8"(300mm)
STR50-P6S36 42 6 36 240 / 600 193 11.8"(300mm)
STR50-S48 48 48 --- 240 215.8 11.8"(300mm)
STR50-P12S36 48 12 36 240 / 600 215.8 11.8"(300mm)
STR50-S56 56 --- 56 240 246.2 11.8"(300mm)
STR50-P6S50 56 6 50 240 / 600 246.2 11.8"(300mm)
STR50-P12S44 56 12 44 240 / 600 246.2 11.8"(300mm)
STR50-P18S38 56 18 38 240 / 600 246.2 11.8"(300mm)
STR50-P12S60 72 12 60 240 / 600 307 11.8"(300mm)
STR50-S72 72 --- 72 240 307 11.8"(300mm)
STR50-S96 96 --- 96 240 398.2 11.8"(300mm)
STR50-P24S72 96 24 72 240 / 600 398.2 11.8"(300mm)
STR50-P12S84 96 12 84 240 / 600 398.2 11.8"(300mm)
